Zipper Bag Making Machine/TPM

Optional Device:

Servo Motor(China Brand, Famous Brand)

Water Proof Zipper Bag Function

Triangle Folding Device

SKU： 32869918048-1-2-1-1-1 分类： Bag Making Machine

Main Technical Variable:

Model

TPM-600

TPM-800

Capacity

40-120pcs/min

Max Bag Making Length

100~520 mm

100~720 mm

Max Bag Making Width

120~500 mm

120~600 mm

Max unwinding material diameter

600mm

Bag making precision

±0.3mm

Main Motor Power

1.5KW

with inverter controlled

2.2KW

with inverter controlled

Power supply

220/380V

Overall Dimensions

7200×1400×2000mm

7200×1600×2000mm

How we know your machinery quality ?

Firstly, welcome to visit our workshop for inspecting our company.
For general model machinery, we can send enough information about the machine to make sure you well understand the quality of us
For customized machine, the design paper can be supplied and similar machine information can be supplied also.
For some model machine, sample can be made on your material sample

How to install machine in our workshop ?

Firstly, you need worker or operator who have the experience to operate similar machine
Most our machine is easily to install, simple operate can start the machine.
The whole operation manual is availabele, and the operation video is available also, and guide on line is available too.
For some complicated machine, engineer come to your place is possible(it is charged)

What about the delivery time ?

For general model of the machine, about 30 working days
For special customized machine, will be longer.

Can you tell us the whole transaction process? What do we need to do to start the transaction?

a).we agree the machinery detail request.
b).You pay 30% deposit, then we start the machinery productioin.
c).when we finished machine production, we will test the machine, the test video will be sent, or you can visit us to inspect the machine quality
d).If no question of the finished machinery, we will pack the machine.
e).Balance Paying before package sending out.

观看视频

点击放大

描述
FAQs

描述

Description:

This machine is suitable for making BOPP\OPP\POF\PE and other printing and non-printing plastic films with bone sticking bags. It is an ideal equipment for making zipper bags, keel bags, bread bags and soft handbags.
Material to be processed:
Various heat-sealable materials such as BOPP, PP, PE, heat-shrinkable film, etc.

Model	TPM-600	TPM-800
Capacity	40-120pcs/min	40-120pcs/min
Max Bag Making Length	100~520 mm	100~720 mm
Max Bag Making Width	120~500 mm	120~600 mm
Max unwinding material diameter	600mm	600mm
Bag making precision	±0.3mm	±0.3mm
Main Motor Power	1.5KW with inverter controlled	2.2KW with inverter controlled
Power supply	220/380V	220/380V
Overall Dimensions	7200×1400×2000mm	7200×1600×2000mm

Zipper Bag Making Machine/TPM

Optional Device:

Description:

Main Technical Variable:

Suitable Bag Sealing and Cutting:

ZIPPER BAG WITHOUT SLIDER(zipper strip is sealed)

ZIPPER BAG WITH SLIDDER

WATER PROOF ZIPPER BAG WITH SLIDDER

How we know your machinery quality ?

How to install machine in our workshop ?

What about the delivery time ?

Can you tell us the whole transaction process? What do we need to do to start the transaction?

Zipper Bag Making Machine/TPM

Optional Device:

Description:

Main Technical Variable:

Suitable Bag Sealing and Cutting:

ZIPPER BAG WITHOUT SLIDER(zipper strip is sealed)

ZIPPER BAG WITH SLIDDER

WATER PROOF ZIPPER BAG WITH SLIDDER
